HIGH FORCE SERVO CONTROL SOLUTION – ELECTRIC HYDRAULIC CYLINDERS

When it comes to actuation technology for high-force applications (>1,000 lbs), machine builders often consider electro-mechanical screw-type actuators or hydraulic cylinders. However, electric hydraulic cylinders, such as Kyntronics' Hybrid Linear Actuators, offer a superior alternative by combining the best features of both technologies.
Category:
Insights, Precision Control

THE CHALLENGES OF TRADITIONAL ACTUATION TECHNOLOGIES

  1. Hydraulic Cylinders: Robust but complex, requiring regular maintenance, and prone to leaks. They are energy-inefficient and often require expensive additional components for precise control.
  2. Electro-Mechanical Actuators: Precise but fragile, with high maintenance costs due to metal-to-metal wear and susceptibility to damage from shock loads.



KYNTRONICS’ HYBRID LINEAR ACTUATORS: A COMPREHENSIVE SOLUTION

Our hybrid linear actuators provide a total solution package for high force applications that includes the actuator, motor, drive system, operating software, and cables. They offer:

  • High Force Capability: Up to 150,000 lbs of force.
  • Precision Servo Control: Ensures accurate position and force control.
  • Energy Efficiency: Uses power-on-demand technology to reduce energy waste.

Minimal Maintenance: Totally sealed design eliminates leaks and reduces maintenance needs.

Hybrid Linear Actuators group image

PRECISION PROCESS CONTROL

Automated equipment requires precision control of the process to produce parts that are in-spec and the same, every cycle. The Kyntronics Hybrid Linear Actuation system was designed with precision control and process documentation in mind. The actuator incorporates a linear position sensor and force measurement pressure transducer as inputs to the servo controller. Available software controls position, force, or combination. Kyntronics “Total Solution” package performs cycle pass/fail determination, captures data for process analysis and machine diagnostics.
